  • Gigabyte 2U Rack Server - 4th/5th Gen Intel xeon Scalable - 3x Gen5 GPUs, 1x Gen3 M.2 Slots, 12 SATA/SAS Bays (R263-S33 rev. AAF1)

Gigabyte 2U Rack Server - 4th/5th Gen Intel xeon Scalable - 3x Gen5 GPUs, 1x Gen3 M.2 Slots, 12 SATA/SAS Bays (R263-S33 rev. AAF1)

Gigabyte

No reviews yet Write a Review
SKU:
CSR263S33AAF1
MPN: R263-S33-AAF1
$2,849.99
Gigabyte 2U Rack Server - 4th/5th Gen Intel xeon Scalable - 3x Gen5 GPUs, 1x Gen3 M.2 Slots, 12 SATA/SAS Bays (R263-S33 rev. AAF1)
UPC:
889523039779
Shipping and Returns

Description

R263-S33 (rev. AAF1) (Datasheet PDF)

Rack Server - 4th/5th Gen Intel Xeon Scalable - 2U UP 12-Bay SATA/SAS

  • Supports up to 3 x Dual slot Gen5 GPU cards
  • 5th Gen Intel Xeon Scalable Processors
  • 4th Gen Intel Xeon Scalable Processors
  • Intel Xeon CPU Max Series
  • Single processor, LGA 4677
  • 8-Channel RDIMM DDR5 per processor, 16 x DIMMs
  • Dual ROM Architecture
  • 1 x 1Gb/s LAN port (Intel I210-AT)
  • 1 x Dedicated management port
  • 12 x 3.5"/2.5" SATA/SAS hot-swappable bays
  • 1 x M.2 slot with PCIe Gen3 x4 interface
  • 3 x FHFL PCIe Gen5 x16 slots for GPUs
  • 2 x OCP 3.0 Gen5 x16 slots
  • 1+1 2400W 80 PLUS Platinum redundant power supplies

Specifications

Brand:
Gigabyte
Weight:
50.00 LBS
Form Factor:
Rackmount
Rack Height:
2U
Dimensions:
39 x 24 x 11 inch
Motherboard:
MS33-DC0
Number of CPUs:
1
CPU:
4th, 5th Generation Intel Xeon Scalable
CPU Specifications:
CPU TDP up to 350W Socket
GPU Integrated:
Yes
Number of DIMM Slots:
16 x DIMM slots
Memory Supported:
8-Channel RDIMM, DDR5 memory supported only
NIC (LAN):
1 x 1Gb/s LAN port (1 x Intel I210-AT), Supports NCSI function
NIC (Management):
1 x 10/100/1000 Mbps Management LAN
Expansion Slots:
3 x PCIe Gen5 x16 FHFL slots 2 x PCIe Gen5 x16 OCP 3.0 slots - Supporte NCSI function 1 x M.2 slot (M-key, PCIe Gen3 x4, NGFF-2280/22110)
Expansion Bays:
12 x 3.5/2.5" SATA/SAS hot-swappable bays SAS card is required for SAS devices support
Power Supply:
Dual 2400W 80 PLUS Platinum redundant power supply
